New Holland
Rostselmash
ACROS 540
Combine
24 specifications
New Holland
CX860
- Operating Weight w/o Attachment
- 34,171 lb
- Fuel Capacity
- 198.0 gal
- Displacement
- 476 in³
- Power
- 330.0 hp
1 / 5
Image 1 of 5
Specifications
24 data points
Operating Specifications
| Operating Weight w/o Attachment | 34,171 lb |
|---|---|
| Fuel Capacity | 198.0 gal |
| Transmission Type | Hydrostatic drive 4-speed gearbox |
| Number of Gears | 4 |
Engine
| Displacement | 476 in³ |
|---|---|
| Power Measured @ | 2,100 rpm |
| Power | 330.0 hp |
Dimensions
| Overall Length | 356 in |
|---|---|
| Width Over Tires | 172 in |
| Height to Top of Isomount Cab | 156 in |
Cleaning System
| Total Cleaning Area | 10,075 in³ |
|---|---|
| Cleaning Fan Speed - High | 900 rpm |
| Cleaning Fan Speed - Low | 475 rpm |
| Self Leveling | — |
Grain Handling
| Grain Tank Capacity | 3,072.0 gal |
|---|---|
| Unloading Speed | 3 bu/sec |
Separating
| Separating Area | 11,083 in³ |
|---|---|
| Separator Length | 145 in |
Threshing
| Rotor Diameter | 30 in |
|---|---|
| Rotor Length | 62 in |
| Rotor Speed - High | 905 rpm |
| Rotor Speed - Low | 305 rpm |
| Concave Area | 1,829 in³ |
| Beater Grate Area | 450 in³ |
