New Holland
Case
CX290B
Excavator
55 specifications
1 / 5
Image 1 of 5
Specifications
26 data points
Operating Specifications
| Operating Weight | 109,300 lb |
|---|---|
| Fuel Capacity | 172.0 gal |
| Hydraulic System Fluid Capacity | 193.0 gal |
| Engine Oil Capacity | 10.0 gal |
| Cooling System Fluid Capacity | 11.0 gal |
| Swing Drive Fluid Capacity | 4.0 gal |
Engine
| Engine Model | M11-C |
|---|---|
| Displacement | 659 in³ |
| Net Power | 303.0 hp |
| Aspiration | Turbo Charged |
Dimensions
| Ground Clearance | 23 in |
|---|---|
| Height - Top of Cab | 131 in |
| Length of Track on Ground | 173 in |
| Tail Swing Radius | 150 in |
| Width to Outside of Tracks | 144 in |
| Removal Counterweight Clearance | 52 in |
Undercarriage
| Ground Pressure | 8 psi |
|---|---|
| Shoe Size | 35 in |
Boom/Stick Excavator Option 1
| Max Digging Depth | 331 in |
|---|---|
| Max Reach Along Ground | 504 in |
| Max Loading Height | 335 in |
| Max Vertical Wall Digging Depth | 190 in |
| Max Cutting Height | 328 in |
| Shipping Length of Unit | 516 in |
| Shipping Height of Unit | 156 in |
Swing Mechanism
| Swing Speed | 7 rpm |
|---|
