Case
Kobelco
SK350LC-10 H&W
Excavator
35 specifications
1 / 5
Image 1 of 5
Specifications
55 data points
Operating Specifications
| Operating Weight | 65,697 lb |
|---|---|
| Fuel Capacity | 118.9 gal |
| Hydraulic Pump Flow Capacity | 64.2 gal/min |
| Hydraulic System Fluid Capacity | 79.3 gal |
| Hydraulic System Relief Valve Pressure | 4,975 psi |
| Engine Oil Capacity | 10.1 gal |
| Cooling System Fluid Capacity | 7.7 gal |
| Operating Voltage | 24 V |
| Swing Drive Fluid Capacity | 1.6 gal |
| Alternator Supplied Amperage | 50 A |
Engine
| Engine Model | 6HK1YSS Tier III certified |
|---|---|
| Displacement | 475 in³ |
| Power Measured @ | 1,800 rpm |
| Net Power | 207.0 hp |
| Aspiration | turbocharged |
| Torque Measured @ | 1,500 rpm |
| Max Torque | 627 lb-ft |
Dimensions
| Ground Clearance | 228 in |
|---|---|
| Height - Top of Cab | 121 in |
| Length of Track on Ground | 157 in |
| Tail Swing Radius | 125 in |
| Width to Outside of Tracks | 134 in |
| Removal Counterweight Clearance | 564 in |
Undercarriage
| Ground Pressure | 6 psi |
|---|---|
| Track Gauge | 102 in |
| Number of Track Rollers per Side | 9 |
| Max Travel Speed | 3.5 mph |
| Shoe Size | 32 in |
| Number of Shoes per Side | 50 |
| Number of Carrier Rollers per Side | 2 |
| Drawbar Pull | 52,425 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 300 in |
|---|---|
| Max Reach Along Ground | 433 in |
| Max Loading Height | 291 in |
| Max Vertical Wall Digging Depth | 264 in |
| Max Cutting Height | 409 in |
| Shipping Length of Unit | 414 in |
| Shipping Height of Unit | 137 in |
Bucket
| Maximum Bucket Capacity | 2.20 yd³ |
|---|---|
| Minimum Bucket Capacity | 0.80 yd³ |
Swing Mechanism
| Swing Speed | 10 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 281 in |
|---|---|
| Max Vertical Wall Digging Depth | 241 in |
| Max Cutting Height | 396 in |
| Max Loading Height | 280 in |
| Max Reach Along Ground | 414 in |
| Shipping Length of Unit | 413 in |
| Shipping Height of Unit | 128 in |
Boom/Stick Excavator Option 3
| Max Digging Depth | 259 in |
|---|---|
| Max Cutting Height | 391 in |
| Max Loading Height | 275 in |
| Max Vertical Wall Digging Depth | 228 in |
| Max Reach Along Ground | 264 in |
| Shipping Length of Unit | 414 in |
| Shipping Height of Unit | 132 in |
