New Holland
JCB
JS240L
Excavator
13 specifications
New Holland
EH214LC
- Operating Weight
- 46,297 lb
- Max Digging Depth
- 264 in
- Max Digging Depth
- 287 in
- Net Power
- 148.0 hp
1 / 5
Image 1 of 5
Specifications
30 data points
Operating Specifications
| Operating Weight | 46,297 lb |
|---|---|
| Fuel Capacity | 89.9 gal |
| Hydraulic Pump Flow Capacity | 116.5 gal/min |
| Hydraulic System Fluid Capacity | 65.0 gal |
| Hydraulic System Relief Valve Pressure | 4,980 psi |
| Engine Oil Capacity | 6.4 gal |
| Cooling System Fluid Capacity | 5.1 gal |
Engine
| Engine Model | 6D34-TLED |
|---|---|
| Displacement | 358 in³ |
| Net Power | 148.0 hp |
Dimensions
| Ground Clearance | 18 in |
|---|---|
| Height - Top of Cab | 117 in |
| Length of Track on Ground | 145 in |
| Tail Swing Radius | 108 in |
| Width to Outside of Tracks | 126 in |
| Removal Counterweight Clearance | 42 in |
Undercarriage
| Max Travel Speed | 3.8 mph |
|---|---|
| Shoe Size | 28 in |
| Drawbar Pull | 44,700 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 264 in |
|---|---|
| Max Reach Along Ground | 384 in |
| Max Loading Height | 268 in |
| Max Vertical Wall Digging Depth | 239 in |
| Max Cutting Height | 378 in |
Swing Mechanism
| Swing Speed | 11 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 287 in |
|---|---|
| Max Vertical Wall Digging Depth | 250 in |
| Max Cutting Height | 376 in |
| Max Loading Height | 267 in |
| Max Reach Along Ground | 41 in |
