New Holland
Hyundai
HSL275T
Skid Steer Loader
26 specifications
1 / 5
Image 1 of 5
Specifications
30 data points
Operating Specifications
| Operating Weight | 2,185 lb |
|---|---|
| Max Speed | 5.8 mph |
| Fuel Capacity | 6.0 gal |
| Hydraulic System Fluid Capacity | 9.0 gal |
| Tire Size | 23X8.50-12 |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 22 A |
| Engine Oil Fluid Capacity | 0.9 gal |
| Cooling System Fluid Capacity | 1.2 gal |
Engine
| Engine Model | NH673 |
|---|---|
| Displacement | 41 in³ |
| Power Measured @ | 3,600 rpm |
| Gross Power | 16.5 hp |
| Number of Cylinders | 3 |
Hydraulic System
| Pump Flow Capacity | 8.0 gal/min |
|---|---|
| Relief Valve Pressure | 1,600 psi |
| Pump Type | Gear type |
Dimensions
| Ground Clearance | 7 in |
|---|---|
| Height - Top of Cab | 70 in |
| Wheelbase | 32 in |
| Width Over Tires | 41 in |
| Reach at Max Lift and Dump | 94 in |
| Length with Bucket | 96 in |
| Clearance at Max Lift and Dump | 22 in |
| Turning Radius from Center - inc bucket | 48 in |
| Turning Radius from Center - machine rear | 71 in |
Loader
| Bucket Capacity | 0.20 yd³ |
|---|---|
| Operating Load Rating | 699 lb |
| Tipping Angle | 1,400 ° |
| Breakout Force | 1,409 psi |
