New Holland
JCB
JS240L
Excavator
13 specifications
.jpg)
1 / 5
Image 1 of 5
Specifications
50 data points
Operating Specifications
| Operating Weight | 45,040 lb |
|---|---|
| Fuel Capacity | 95.2 gal |
| Hydraulic Pump Flow Capacity | 118.9 gal/min |
| Hydraulic System Fluid Capacity | 37.0 gal |
| Hydraulic System Relief Valve Pressure | 5,004 psi |
| Engine Oil Capacity | 4.3 gal |
| Cooling System Fluid Capacity | 8.0 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 70 A |
| Tire Size | 10.00-20 |
Engine
| Engine Model | CNH - F4BE0684A |
|---|---|
| Displacement | 360 in³ |
| Net Power | 152.0 hp |
| Number of Cylinders | 6 |
| Aspiration | Turbocharger and charge air cooling |
Dimensions
| Ground Clearance | 13 in |
|---|---|
| Height - Top of Cab | 121 in |
| Wheelbase | 104 in |
| Overall Width | 8 in |
| Tail Swing Radius | 81 in |
| Upper Structure Clearance | 50 in |
| Overall Width - Outriggers Down | 154 in |
Transmission
| Max Travel Speed | 12.5 mph |
|---|---|
| Drawbar Pull | 25,853 lb |
Bucket
| Reference Bucket Capacity | 0.80 yd³ |
|---|---|
| Maximum Bucket Capacity | 1.29 yd³ |
| Minimum Bucket Capacity | 0.71 yd³ |
Swing Mechanism
| Swing Speed | 10 rpm |
|---|---|
| Swing Torque | 39,090 lb-ft |
Boom/Stick Mobile Excavator Option 1
| Max Digging Depth | 211 in |
|---|---|
| Max Cutting Height | 394 in |
| Max Reach Along Ground | 350 in |
| Max Loading Height | 278 in |
| Shipping Length of Unit | 347 in |
| Shipping Height of Unit | 121 in |
| Max Vertical Wall Dig Depth | 146 in |
Boom/Stick Mobile Excavator Option 2
| Max Digging Depth | 227 in |
|---|---|
| Max Cutting Height | 406 in |
| Max Reach Along Ground | 366 in |
| Max Loading Height | 291 in |
| Shipping Height of Unit | 121 in |
| Shipping Length of Unit | 347 in |
| Max Vertical Wall Dig Depth | 161 in |
Boom/Stick Mobile Excavator Option 3
| Max Digging Depth | 243 in |
|---|---|
| Max Cutting Height | 419 in |
| Max Reach Along Ground | 381 in |
| Max Loading Height | 304 in |
| Shipping Height of Unit | 122 in |
| Shipping Length of Unit | 346 in |
| Max Vertical Wall Dig Depth | 175 in |
