Ingersoll Rand
DD14S
Smooth Drum Roller
17 specifications
1 / 5
Image 1 of 5
Specifications
18 data points
Operating Specifications
| Operating Weight | 4,409 lb |
|---|---|
| Max Speed | 4.4 mph |
| Fuel Capacity | 9.3 gal |
| Hydraulic System Fluid Capacity | 36.5 gal |
Engine
| Engine Model | D1403 |
|---|---|
| Power Measured @ | 2,800 rpm |
| Gross Power | 26.7 hp |
| Number of Cylinders | 3 |
Dimensions
| Height - Top of Cab | 90 in |
|---|---|
| Overall Length | 10 in |
| Overall Width | 55 in |
| Drum Diameter - Front | 31 in |
Drum
| Drum Width | 36 in |
|---|---|
| Drum Diameter | 31 in |
| Vibration Frequency 1 | 34 vpm |
| Nominal Amplitude - High | 0 in |
| Centrifugal Force - High | 14,388 lb |
| Static Linear Load | 6 lb-ft |
