SV400TF

Padfoot Compactor

Operating Weight
19,290 lb
Max Speed
6.3 mph
Drum Width
67 in
Gross Power
81.9 hp
All padfoot compactors
Sakai SV400TF Padfoot Compactor
1 / 5
Image 1 of 5
Image: etlhire.co.nz

Specifications

22 data points

Operating Specifications

Operating Specifications specifications
Operating Weight19,290 lb
Max Speed6.3 mph
Fuel Capacity47.6 gal
Hydraulic System Fluid Capacity13.3 gal
Operating Voltage24 V

Engine

Engine specifications
Engine ModelA-4BG1
Displacement264 in³
Gross Power81.9 hp

Dimensions

Dimensions specifications
Ground Clearance13 in
Height - Top of Cab113 in
Wheelbase9 in
Width Over Tires74 in
Overall Length w/o Blade192 in

Tires & Wheels

Tires & Wheels specifications
Tires16.9-24-10PR(OR)

Drum

Drum specifications
Drum Width67 in
Vibration Frequency 140 vpm
Centrifugal Force - High28,551 lb
Drum Diameter55 in
Pad Height3 in
Number of Pads140
Centrifugal Force - Low23,155 lb
Vibratory Frequency 230 vpm
