Salford
Rostselmash
ACROS 540
Combine
24 specifications
1 / 5
Image 1 of 5
Specifications
25 data points
Operating Specifications
| Operating Weight w/o Attachment | 32,077 lb |
|---|---|
| Fuel Capacity | 153.3 gal |
| Transmission Type | hydrostatic |
| Number of Gears | — |
Engine
| Engine Model | Cursor 9 |
|---|---|
| Power Measured @ | 2,100 rpm |
| Power | 272.0 hp |
| Power Boost Power | 303.0 hp |
Dimensions
| Overall Length | 322 in |
|---|---|
| Width Over Tires | 126 in |
| Height to Top of Isomount Cab | 156 in |
Cleaning System
| Total Cleaning Area | 6,696 in³ |
|---|---|
| Cleaning Fan Speed - High | 1,000 rpm |
| Cleaning Fan Speed - Low | 165 rpm |
| Self Leveling | 0 |
Grain Handling
| Grain Tank Capacity | 1,981.9 gal |
|---|---|
| Unloading Speed | 2.1 bu/sec |
Separating
| Separating Area | 3,082 in³ |
|---|---|
| Discharge Grate Area | 8,339 in³ |
Threshing
| Rotor Diameter | 24 in |
|---|---|
| Rotor Length | 51 in |
| Rotor Speed - High | 1,140 rpm |
| Rotor Speed - Low | 400 rpm |
| Concave Area | 1,333 in³ |
| Beater Grate Area | 443 in³ |
