Salford
Rostselmash
ACROS 540
Combine
24 specifications
1 / 5
Image 1 of 5
Specifications
23 data points
Operating Specifications
| Operating Weight w/o Attachment | 30,865 lb |
|---|---|
| Fuel Capacity | 264.2 gal |
| Transmission Type | hydrostatic |
| Number of Gears | 4 |
Engine
| Engine Model | Cursor 10 |
|---|---|
| Power Measured @ | 2,100 rpm |
| Power | 405.0 hp |
| Power Boost Power | 455.0 hp |
Dimensions
| Overall Length | 357 in |
|---|---|
| Width Over Tires | 138 in |
| Height to Top of Isomount Cab | 156 in |
Cleaning System
| Total Cleaning Area | 10,137 in³ |
|---|---|
| Cleaning Fan Speed - High | 900 rpm |
| Cleaning Fan Speed - Low | 475 rpm |
Grain Handling
| Grain Tank Capacity | 2,377.6 gal |
|---|---|
| Unloading Speed | 3.2 bu/sec |
Separating
| Separating Area | 9,192 in³ |
|---|---|
| Separator Type | rotary |
Threshing
| Rotor Diameter | 30 in |
|---|---|
| Rotor Length | 62 in |
| Rotor Speed - High | 905 rpm |
| Rotor Speed - Low | 305 rpm |
| Concave Area | 1,829 in³ |
