JCB
JS240L
Excavator
13 specifications
1 / 5
Image 1 of 5
Specifications
27 data points
Operating Specifications
| Operating Weight | 49,736 lb |
|---|---|
| Fuel Capacity | 92.5 gal |
| Hydraulic Pump Flow Capacity | 105.7 gal/min |
| Hydraulic System Relief Valve Pressure | 4,980 psi |
Engine
| Engine Model | B5.9-C |
|---|---|
| Displacement | 360 in³ |
| Power Measured @ | 1,900 rpm |
| Net Power | 143.0 hp |
| Torque Measured @ | 1,500 rpm |
| Max Torque | 456 lb-ft |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Height - Top of Cab | 125 in |
| Length of Track on Ground | 145 in |
| Tail Swing Radius | 113 in |
| Width to Outside of Tracks | 126 in |
| Removal Counterweight Clearance | 41 in |
Undercarriage
| Track Gauge | 95 in |
|---|---|
| Max Travel Speed | 3.4 mph |
| Shoe Size | 32 in |
Boom/Stick Excavator Option 1
| Max Digging Depth | 476 in |
|---|---|
| Max Reach Along Ground | 619 in |
| Max Loading Height | 432 in |
| Max Cutting Height | 524 in |
| Shipping Length of Unit | 505 in |
| Shipping Height of Unit | 125 in |
Bucket
| Reference Bucket Capacity | 0.71 yd³ |
|---|
Swing Mechanism
| Swing Speed | 12 rpm |
|---|
