Sany
Caterpillar
120G
Motor Grader
17 specifications
1 / 5
Image 1 of 5
Specifications
22 data points
Operating Specifications
| Std Operation Weight - Total | 35,869 lb |
|---|
Engine
| Engine Model | QSB6.7 |
|---|---|
| Power Measured @ | 2,200 rpm |
| Number of Cylinders | 6 |
| Max Power | 258.9 hp |
| Net Power Gear 1-2 | 193.2 hp |
Dimensions
| Overall Length | 359 in |
|---|---|
| Width Over Tires | 104 in |
| Height to Top of Isomount Cab | 127 in |
Transmission
| Max Speed - Forward | 19.9 mph |
|---|---|
| Number of Gears - Forward | 6 |
| Number of Gears - Reverse | 3 |
Moldboard
| Moldboard Height | 24 in |
|---|---|
| Moldboard Width | 157 in |
| Moldboard Thickness | 1 in |
Circle
| Max Lift Above Ground | 17 in |
|---|---|
| Max Reach Outside Tires - Left | 2 in |
| Max Reach Outside Tires - Right | 3 in |
| Blade Tip Angle - Front | 90 ° |
Front Axle
| Wheel Lean | 17 ° |
|---|---|
| Oscillation - Total | 15 ° |
Steering System
| Turning Radius | 245 in |
|---|
