Sany
Terex
A600
Rough Terrain Crane
31 specifications
1 / 5
Image 1 of 5
Specifications
25 data points
Operating Specifications
| Operating Weight | 99,164 lb |
|---|---|
| Fuel Capacity | 79.3 gal |
| Tire Size | 29.5 R 25 |
| Operating Voltage | 24 V |
| Hydraulic System Fluid Capacity | 196.3 gal |
Engine
| Power Measured @ | 2,500 rpm |
|---|---|
| Gross Power | 265.6 hp |
| Torque Measured @ | 1,500 rpm |
| Max Torque | 715 lb-ft |
Dimensions
| Ground Clearance | 20 in |
|---|---|
| Wheelbase | 158 in |
| Transport Width | 131 in |
| Transport Height | 149 in |
| Transport Length | 564 in |
| Width w/ Outriggers Extended | 284 in |
| Upper Structure Tail Swing Radius | 172 in |
| Carrier/Base Length | 332,480 in |
Transmission
| Number of Forward Gears | 6 |
|---|---|
| Number of Reverse Gears | 6 |
| Transmission Type | Automatic |
Boom
| Max Lift Capacity | 121,254 lb |
|---|---|
| Max Height @ Max Raise Angle - no jib | 1,693 in |
| Min Height @ Max Raise Angle | 454 in |
| Max Elevating Angle | 80 ° |
| Number of Sections | 5 |
