Sany

SY420

Excavator

Operating Weight
91,712 lb
Max Digging Depth
308 in
Net Power
315.2 hp
All excavators
Sany SY420 Excavator
1 / 5
Image 1 of 5
Image: sanyexcavator.com

Specifications

19 data points

Operating Specifications

Operating Specifications specifications
Operating Weight91,712 lb
Hydraulic Pump Flow Capacity190.3 gal/min

Engine

Engine specifications
Engine Model6D24-TLU2G
Displacement729 in³
Power Measured @2,000 rpm
Net Power315.2 hp

Dimensions

Dimensions specifications
Ground Clearance23 in
Length of Track on Ground158 in
Tail Swing Radius191 in
Width to Outside of Tracks132 in

Undercarriage

Undercarriage specifications
Max Travel Speed3.3 mph
Shoe Size24 in

Boom/Stick Excavator Option 1

Boom/Stick Excavator Option 1 specifications
Max Digging Depth308 in
Max Reach Along Ground473 in
Max Loading Height298 in
Max Vertical Wall Digging Depth272 in
Shipping Length of Unit475 in
Shipping Height of Unit159 in

Bucket

Bucket specifications
Reference Bucket Capacity2.69 yd³
