Tadano
TR-300EX
- Operating Weight
- 59,745 lb
- Max Lift Capacity
- 66,139 lb
- Max Speed - Forward
- 31.1 mph
- Gross Power
- 212.1 hp
1 / 5
Image 1 of 5
Specifications
33 data points
Operating Specifications
| Operating Weight | 59,745 lb |
|---|---|
| Fuel Capacity | 79.3 gal |
| Tire Size | 16.00 x 25 |
| Operating Voltage | 24 V |
| Hydraulic System Fluid Capacity | 108.4 gal |
Engine
| Engine Model | 6D16T |
|---|---|
| Displacement | 461 in³ |
| Power Measured @ | 2,800 rpm |
| Gross Power | 212.1 hp |
| Number of Cylinders | 6 |
| Torque Measured @ | 1,600 rpm |
| Max Torque | 470 lb-ft |
| Engine Make | Mitsubishi |
| Stroke | 5 in |
| Bore | 5 in |
| Engine Type | Direct Injection Diesel |
Dimensions
| Wheelbase | 136 in |
|---|---|
| Transport Width | 103 in |
| Transport Height | 139 in |
| Transport Length | 433 in |
| Width w/ Outriggers Extended | 248 in |
| Upper Structure Tail Swing Radius | 132 in |
| Carrier/Base Length | 358,269 in |
Transmission
| Max Speed - Forward | 31.1 mph |
|---|---|
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 1 |
| Transmission Type | Full powershift |
Boom
| Max Lift Capacity | 66,139 lb |
|---|---|
| Max Height @ Max Raise Angle - no jib | 1,127 in |
| Min Height @ Max Raise Angle | 359 in |
| Max Elevating Angle | 80 ° |
| Number of Sections | 4 |
| Swing Speed | 3 rpm |
