Tadano
TR-300XL-4
- Operating Weight
- 59,633 lb
- Max Lift Capacity
- 60,000 lb
- Max Speed - Forward
- 29.3 mph
- Gross Power
- 173.0 hp
1 / 5
Image 1 of 5
Specifications
33 data points
Operating Specifications
| Operating Weight | 59,633 lb |
|---|---|
| Fuel Capacity | 79.3 gal |
| Tire Size | 20.5-25 24PR |
| Operating Voltage | 24 V |
| Hydraulic System Fluid Capacity | 100.4 gal |
| Cooling System Fluid Capacity | 2.6 gal |
| Engine Oil Capacity | 3.8 gal |
Engine
| Engine Model | QSB5.9-30TAA |
|---|---|
| Displacement | 360 in³ |
| Power Measured @ | 2,500 rpm |
| Gross Power | 173.0 hp |
| Aspiration | turbocharged + aftercooled |
| Torque Measured @ | 1,500 rpm |
| Max Torque | 530 lb-ft |
Dimensions
| Wheelbase | 12 in |
|---|---|
| Transport Width | 108 in |
| Transport Height | 139 in |
| Transport Length | 443 in |
| Width w/ Outriggers Extended | 248 in |
| Upper Structure Tail Swing Radius | 132 in |
| Carrier/Base Length | 289 in |
Transmission
| Max Speed - Forward | 29.3 mph |
|---|---|
| Number of Forward Gears | 8 |
| Number of Reverse Gears | 2 |
| Transmission Type | Electronically controlled full automatic transmission |
Boom
| Max Lift Capacity | 60,000 lb |
|---|---|
| Max Height @ Max Raise Angle - no jib | 1,220 in |
| Min Height @ Max Raise Angle | 381 in |
| Max Elevating Angle | 81 ° |
| Number of Sections | 4 |
| Swing Speed | 3 rpm |
| Min Operating Radius | 120 in |
| Max Operating Radius | 1,080 in |
