Tadano
Grove
RT625
Rough Terrain Crane
38 specifications
1 / 5
Image 1 of 5
Specifications
38 data points
Operating Specifications
| Operating Weight | 59,966 lb |
|---|---|
| Fuel Capacity | 79.3 gal |
| Tire Size | 20.5-25 24PR |
| Operating Voltage | 24 V |
| Hydraulic System Fluid Capacity | 120.5 gal |
| Cooling System Fluid Capacity | 3.5 gal |
Engine
| Engine Model | 6D16T |
|---|---|
| Displacement | 461 in³ |
| Power Measured @ | 2,800 rpm |
| Net Power | 211.9 hp |
| Number of Cylinders | 6 |
| Aspiration | Direct injection diesel |
| Torque Measured @ | 1,600 rpm |
| Max Torque | 470 lb-ft |
| Engine Make | Mitsubishi |
| Stroke | 5 in |
| Bore | 5 in |
| Air cleaner | Dry type replaceable element |
| Cooling system | Liquid pressurized recirculating bypass |
| Radiator Core type | Fin and tube core thermostat controlled |
| Fuel Filter | Full flow with replaceable element |
| Oil Filter | Full flow with replaceable element |
Dimensions
| Wheelbase | 136 in |
|---|---|
| Transport Width | 108 in |
| Transport Height | 139 in |
| Transport Length | 433 in |
| Width w/ Outriggers Extended | 264 in |
| Upper Structure Tail Swing Radius | 131 in |
| Carrier/Base Length | 289,371 in |
Transmission
| Max Speed - Forward | 31.2 mph |
|---|---|
| Number of Forward Gears | 6 |
| Number of Reverse Gears | 2 |
| Transmission Type | Electronically controlled full automatic transmission |
Boom
| Max Height @ Max Raise Angle - no jib | 1,127 in |
|---|---|
| Min Height @ Max Raise Angle | 359 in |
| Max Elevating Angle | 80 ° |
| Number of Sections | 4 |
| Swing Speed | 3 rpm |
