Tadano
Grove
RT625
Rough Terrain Crane
38 specifications
1 / 5
Image 1 of 5
Specifications
29 data points
Operating Specifications
| Operating Weight | 83,313 lb |
|---|---|
| Fuel Capacity | 79.3 gal |
| Tire Size | 18.00 R 25 |
| Operating Voltage | 24 V |
| Hydraulic System Fluid Capacity | 171.8 gal |
Engine
| Engine Model | PF6T |
|---|---|
| Displacement | 763 in³ |
| Power Measured @ | 2,100 rpm |
| Gross Power | 286.1 hp |
| Number of Cylinders | 6 |
| Aspiration | Water-cooled |
| Torque Measured @ | 1,200 rpm |
| Max Torque | 882 lb-ft |
| Engine Make | Nissan |
Dimensions
| Wheelbase | 191 in |
|---|---|
| Transport Width | 119 in |
| Transport Height | 149 in |
| Transport Length | 470 in |
| Width w/ Outriggers Extended | 285 in |
| Carrier/Base Length | 285,433 in |
Transmission
| Max Speed - Forward | 28.0 mph |
|---|---|
| Number of Forward Gears | 3 |
| Number of Reverse Gears | 1 |
| Transmission Type | Powershift |
Boom
| Max Height @ Max Raise Angle - no jib | 1,622 in |
|---|---|
| Min Height @ Max Raise Angle | 383 in |
| Max Elevating Angle | 83 ° |
| Number of Sections | 6 |
| Swing Speed | 2 rpm |
