Tadano

TR-650XL-3

Rough Terrain Crane

Operating Weight
105,934 lb
Max Speed - Forward
24.9 mph
Gross Power
223.0 hp
All rough terrain cranes
Tadano TR-650XL-3 Rough Terrain Crane
1 / 5
Image 1 of 5
Image: constructionequipmentguide.com

Specifications

33 data points

Operating Specifications

Operating Specifications specifications
Operating Weight105,934 lb
Fuel Capacity79.3 gal
Tire Size29.5-25 22PR
Operating Voltage24 V
Hydraulic System Fluid Capacity195.5 gal
Cooling System Fluid Capacity3.5 gal
Engine Oil Capacity4.3 gal

Engine

Engine specifications
Engine Model6D16-TLEE
Displacement460 in³
Power Measured @2,700 rpm
Gross Power223.0 hp
Aspirationturbocharged + aftercooled
Torque Measured @1,300 rpm
Max Torque521 lb-ft

Dimensions

Dimensions specifications
Wheelbase13 in
Transport Width131 in
Transport Height150 in
Transport Length560 in
Width w/ Outriggers Extended284 in
Upper Structure Tail Swing Radius163 in
Carrier/Base Length330 in

Transmission

Transmission specifications
Max Speed - Forward24.9 mph
Number of Forward Gears6
Number of Reverse Gears2
Transmission TypeElectronically controlled full automatic transmission

Boom

Boom specifications
Max Height @ Max Raise Angle - no jib1,733 in
Min Height @ Max Raise Angle452 in
Max Elevating Angle81 °
Number of Sections5
Swing Speed2 rpm
Min Operating Radius120 in
Max Operating Radius1,440 in
Height2,424 in
