PC20R-8
Mini Excavator
47 specifications
1 / 5
Image 1 of 5
Specifications
32 data points
Operating Specifications
| Operating Weight | 7,948 lb |
|---|---|
| Fuel Capacity | 14.1 gal |
| Hydraulic Pump Flow Capacity | 6.9 gal/min |
| Hydraulic System Fluid Capacity | 17.7 gal |
| Hydraulic System Relief Valve Pressure | 3,000 psi |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 40 A |
| Engine Oil Capacity | 1.3 gal |
| Cooling System Fluid Capacity | 2.3 gal |
Engine
| Engine Model | 3TNV88 |
|---|---|
| Displacement | 100 in³ |
| Power Measured @ | 2,400 rpm |
| Gross Power | 29.8 hp |
| Net Power | 28.8 hp |
| Number of Cylinders | 3 |
| Torque Measured @ | 1,440 rpm |
| Max Torque | 79 lb-ft |
Dimensions
| Ground Clearance | 12 in |
|---|---|
| Height - Top of Cab | 97 in |
| Length of Track on Ground | 66 in |
| Tail Swing Radius | 55 in |
| Width to Outside of Tracks | 65 in |
Undercarriage
| Ground Pressure | 4 psi |
|---|---|
| Number of Track Rollers per Side | 4 |
| Max Travel Speed | 3.2 mph |
| Shoe Size | 14 in |
Boom/Stick Excavator Option 1
| Max Digging Depth | 134 in |
|---|---|
| Max Reach Along Ground | 211 in |
| Max Vertical Wall Digging Depth | 103 in |
| Max Loading Height | 151 in |
| Shipping Length of Unit | 198 in |
| Shipping Height of Unit | 97 in |
