Terex
JCB
JS240L
Excavator
13 specifications
1 / 5
Image 1 of 5
Specifications
33 data points
Operating Specifications
| Operating Weight | 52,911 lb |
|---|---|
| Fuel Capacity | 79.3 gal |
| Hydraulic Pump Flow Capacity | 84.6 gal/min |
| Hydraulic System Fluid Capacity | 101.8 gal |
| Hydraulic System Relief Valve Pressure | 55 psi |
| Engine Oil Capacity | 5.6 gal |
| Operating Voltage | 24 V |
Engine
| Engine Model | BF6M 1013 ECP |
|---|---|
| Displacement | 436 in³ |
| Power Measured @ | 2,000 rpm |
| Net Power | 213.0 hp |
| Aspiration | Turbocharging/intercooler |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Height - Top of Cab | 121 in |
| Length of Track on Ground | 148 in |
| Tail Swing Radius | 107 in |
| Width to Outside of Tracks | 119 in |
| Removal Counterweight Clearance | 47 in |
Undercarriage
| Track Gauge | 95 in |
|---|---|
| Max Travel Speed | 3.3 mph |
| Shoe Size | 24 in |
Boom/Stick Excavator Option 1
| Max Digging Depth | 253 in |
|---|---|
| Max Cutting Height | 441 in |
Bucket
| Reference Bucket Capacity | 1.70 yd³ |
|---|---|
| Maximum Bucket Capacity | 2.00 yd³ |
| Minimum Bucket Capacity | 1.70 yd³ |
Swing Mechanism
| Swing Speed | 9 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 270 in |
|---|---|
| Max Cutting Height | 458 in |
Boom/Stick Excavator Option 3
| Max Digging Depth | 251 in |
|---|---|
| Max Cutting Height | 359 in |
Boom/Stick Excavator Option 4
| Max Digging Depth | 270 in |
|---|---|
| Max Cutting Height | 365 in |
