Terex
Volvo
A35E
Off-Highway Truck
44 specifications
1 / 5
Image 1 of 5
Specifications
19 data points
Operating Specifications
| Fuel Capacity | 220.0 gal |
|---|---|
| Tire Size | 24.00 x 35-36PR |
| Alternator Supplied Amperage | — |
Engine
| Engine Model | DD 16V-71T |
|---|---|
| Net Power | 624.0 hp |
Weights
| Empty Weight | 93,200 lb |
|---|---|
| Loaded Weight | 203,200 lb |
Dimensions
| Wheelbase | 169 in |
|---|---|
| Overall Length | 380 in |
| Overall Width | 179 in |
| Overall Height | 320 in |
Transmission
| Max Speed | 42.0 mph |
|---|---|
| Transmission Type | Allison CLBT-6061 |
| Number of Gears - Forward | 6 |
| Number of Gears - Reverse | 1 |
Service Refill Capacities
| Brake/Hoist Hydraulic Tank | 109,988.0 gal |
|---|
Dump
| Rated Payload | 110,000 lb |
|---|---|
| Load Capacity - heaped | 44.10 yd³ |
| Load Capacity - Struck | 33.69 yd³ |
