Terex

AC 500-2

All Terrain Crane

Gross Power
643.7 hp
Max Speed - Forward
39.8 mph
Transport Width
119 in
All all terrain cranes
Terex AC 500-2 All Terrain Crane
1 / 5
Image 1 of 5
Image: cranenetwork.com

Specifications

32 data points

Operating Specifications

Operating Specifications specifications
Operating Weight211,644 lb
Tire Size14R25
Carrier Fuel Capacity155.9 gal
Operating Voltage24 V
Number of Axels8
Upper Structure Fuel Capacity79.3 gal

Dimensions

Dimensions specifications
Transport Width119 in
Transport Height158 in
Transport Length759 in
Width w/ Outriggers Extended378 in
Upper Structure Tail Swing Radius241 in
Carrier Length676 in

Transmission

Transmission specifications
Max Speed - Forward39.8 mph
Transmission TypeZF-TC-Tronic automated

Boom

Boom specifications
Number of Sections4
Max Height @ Max Raise Angle - no jib2,323 in
Min Height @ Max Raise Angle630 in
Max Elevating Angle83 °
Swing Speed1 rpm
Min Working Radius119 in
Max Working Radius2,048 in
Height5,736 in

CARRIER ENGINE

CARRIER ENGINE specifications
Gross Power643.7 hp
Max Torque2,065 lb-ft
Torque Measured @1,200 rpm
MakeTerex
Power Measured @1,800 rpm

UPPER STRUCTURE ENGINE

UPPER STRUCTURE ENGINE specifications
Gross Power275.0 hp
MakeTerex
Max Torque811 lb-ft
Torque Measured @1,600 rpm
Power Measured @2,200 rpm
