Terex
Hitachi
EX8000
Mini Excavator
35 specifications
1 / 5
Image 1 of 5
Specifications
31 data points
Operating Specifications
| Operating Weight | 2,156,000 lb |
|---|---|
| Fuel Capacity | 4,226.3 gal |
| Hydraulic System Fluid Capacity | 2,641.5 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 350 A |
| Swing Speed | 4 rpm |
Engine
| Engine Model | 2 x QSK 60-C |
|---|---|
| Displacement | 4,210 in³ |
| Power Measured @ | 1,800 rpm |
| Gross Power | 4,500.1 hp |
| Net Power | 4,500.1 hp |
| Number of Cylinders | 16 |
| Aspiration | Turbocharged and aftercooled |
Dimensions
| Height - Top of Cab | 401 in |
|---|---|
| Length of Track on Ground | 333 in |
| Upper Structure Ground Clearance | 125 in |
| Length of Tracks | 433 in |
| Height of Tracks | 117 in |
Undercarriage
| Track Gauge | 260 in |
|---|---|
| Max Travel Speed | 1.4 mph |
| Number of Upper Rollers | 2 |
| Loading Shovel Operating Weight | 2,160,530 lb |
| Loading Shovel Shoe Width | 79 in |
| Loading Shovel Ground Pressure | 31 psi |
| Number of Lower Rollers | 7 |
| Number of Track Shoes per Side | 48 |
Bucket
| Reference Bucket Capacity | 58.90 yd³ |
|---|
Loading Shovel
| Max Dig Depth | 91 in |
|---|---|
| Max Dig Reach | 749 in |
| Max Cutting Height | 796 in |
| Max Dump Height | 571 in |
