Terex
Grove
RT625
Rough Terrain Crane
38 specifications
1 / 5
Image 1 of 5
Specifications
28 data points
Operating Specifications
| Operating Weight | 63,260 lb |
|---|---|
| Fuel Capacity | 50.0 gal |
| Tire Size | 23.5R25 |
| Operating Voltage | 24 V |
| Hydraulic System Fluid Capacity | 114.0 gal |
| Alternator Supplied Amperage | 100 A |
Engine
| Engine Model | QSB5.9 |
|---|---|
| Displacement | 360 in³ |
| Power Measured @ | 2,500 rpm |
| Gross Power | 160.0 hp |
| Net Power | 155.0 hp |
| Aspiration | Turbocharged |
| Torque Measured @ | 1,500 rpm |
| Max Torque | 440 lb-ft |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Transport Width | 122 in |
| Transport Height | 124 in |
| Transport Length | 466 in |
| Width w/ Outriggers Extended | 282 in |
| Carrier/Base Length | 287 in |
Transmission
| Max Speed - Forward | 24.5 mph |
|---|---|
| Number of Forward Gears | 6 |
| Number of Reverse Gears | 6 |
| Transmission Type | Powershift Transmission |
Boom
| Max Height @ Max Raise Angle - no jib | 1,128 in |
|---|---|
| Min Height @ Max Raise Angle | 360 in |
| Number of Sections | 4 |
| Swing Speed | 3 rpm |
