Terex
Grove
RT625
Rough Terrain Crane
38 specifications
1 / 5
Image 1 of 5
Specifications
30 data points
Operating Specifications
| Operating Weight | 85,694 lb |
|---|---|
| Fuel Capacity | 50.0 gal |
| Tire Size | 29.50 x 25 28 P.R. |
| Operating Voltage | 24 V |
| Hydraulic System Fluid Capacity | 116.0 gal |
| Alternator Supplied Amperage | 102 A |
Engine
| Engine Model | QSB215 |
|---|---|
| Displacement | 359 in³ |
| Power Measured @ | 2,500 rpm |
| Gross Power | 255.0 hp |
| Net Power | 215.0 hp |
| Aspiration | Turbocharged & charge air cooled |
| Torque Measured @ | 1,500 rpm |
| Max Torque | 655 lb-ft |
Dimensions
| Ground Clearance | 24 in |
|---|---|
| Wheelbase | 13 in |
| Transport Width | 119 in |
| Transport Height | 150 in |
| Transport Length | 552 in |
| Width w/ Outriggers Extended | 312 in |
| Carrier/Base Length | 325 in |
Transmission
| Max Speed - Forward | 23.4 mph |
|---|---|
| Number of Forward Gears | 6 |
| Number of Reverse Gears | 6 |
| Transmission Type | Power-Shift Transmission |
Boom
| Max Height @ Max Raise Angle - no jib | 1,332 in |
|---|---|
| Min Height @ Max Raise Angle | 432 in |
| Max Elevating Angle | 76 ° |
| Number of Sections | 4 |
| Swing Speed | 2 rpm |
