Thomas

35

Mini Excavator

Operating Weight
7,121 lb
Max Digging Depth
135 in
Net Power
29.0 hp
All mini excavators
Thomas 35 Mini Excavator
1 / 5
Image 1 of 5
Image: torosce.com

Specifications

21 data points

Operating Specifications

Operating Specifications specifications
Operating Weight7,121 lb
Fuel Capacity10.6 gal
Hydraulic Pump Flow Capacity28.9 gal/min
Hydraulic System Relief Valve Pressure8,463 psi

Engine

Engine specifications
Engine Model3LD1PA-04
Displacement91 in³
Power Measured @2,400 rpm
Net Power29.0 hp

Dimensions

Dimensions specifications
Height - Top of Cab93 in
Length of Track on Ground65 in
Tail Swing Radius56 in
Width to Outside of Tracks62 in

Undercarriage

Undercarriage specifications
Track Gauge50 in
Max Travel Speed2.9 mph
Shoe Size12 in

Boom/Stick Excavator Option 1

Boom/Stick Excavator Option 1 specifications
Max Digging Depth135 in
Max Vertical Wall Digging Depth101 in
Max Loading Height148 in
Shipping Length of Unit198 in
Max Cutting Height206 in

Swing Mechanism

Swing Mechanism specifications
Swing Speed9 rpm
