Wacker Neuson
Komatsu
PC20R-8
Mini Excavator
47 specifications
1 / 5
Image 1 of 5
Specifications
37 data points
Operating Specifications
| Operating Weight | 4,299 lb |
|---|---|
| Fuel Capacity | 5.8 gal |
| Hydraulic Pump Flow Capacity | 10.5 gal/min |
| Hydraulic System Fluid Capacity | 5.6 gal |
| Hydraulic System Relief Valve Pressure | 3,481 psi |
Engine
| Engine Model | 3TNV80F |
|---|---|
| Displacement | 77 in³ |
| Power Measured @ | 2,200 rpm |
| Net Power | 17.2 hp |
| Number of Cylinders | 3 |
| Aspiration | Water-cooled |
| Engine Make | Yanmar |
Dimensions
| Ground Clearance | 7 in |
|---|---|
| Height - Top of Cab | 94 in |
| Length of Track on Ground | 142 in |
| Tail Swing Radius | 26 in |
| Width to Outside of Tracks | 40 in |
Undercarriage
| Max Travel Speed | 3.0 mph |
|---|---|
| Shoe Size | 9 in |
Boom/Stick Excavator Option 1
| Max Digging Depth | 93 in |
|---|---|
| Max Reach Along Ground | 152 in |
| Max Vertical Wall Digging Depth | 69 in |
| Max Loading Height | 96 in |
| Shipping Length of Unit | 142 in |
| Max Cutting Height | 137 in |
| Shipping Height of Unit | 94 in |
General Specifications
| Operating Weight lbs (kg) | 3,637 (1,650) — Starting 2025 Model Year |
|---|---|
| Digging Depth ft (m) | 8.2 (2.5) — Starting 2025 Model Year |
| Engine hp (kW) | 17.2 (12.8) — Starting 2025 Model Year |
| Digging Reach ft. (m) | 13.2 (4.02) — Starting 2025 Model Year |
Boom/Stick Excavator Option 2
| Max Digging Depth | 98 in |
|---|---|
| Max Cutting Height | 142 in |
| Max Loading Height | 101 in |
| Max Vertical Wall Digging Depth | 74 in |
| Max Reach Along Ground | 158 in |
| Shipping Height of Unit | 94 in |
| Shipping Length of Unit | 141 in |
