TigercatTigercat
822C
Feller Buncher
19 specifications
1 / 5
Image 1 of 5
Specifications
19 data points
Operating Specifications
| Operating Weight w/o Attachment | 72,003 lb |
|---|---|
| Fuel Capacity | 140.1 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 110 A |
| Hydraulic System Fluid Capacity | 43.6 gal |
Engine
| Engine Model | QSL9 |
|---|---|
| Power Measured @ | 1,800 rpm |
| Gross Power | 300.0 hp |
Dimensions
| Ground Clearance | 2 in |
|---|---|
| Height - Top of Cab | 148 in |
| Overall Width | 132 in |
Undercarriage
| Shoe Size | 24 in |
|---|---|
| Track Pitch | 9 in |
Boom
| Bare Pin Lift at Max Reach | 10,108 lb |
|---|---|
| Max Cut Radius | 330 in |
| Min Cut Radius | 128 in |
Upperstructure Leveling
| Front | 26 ° |
|---|---|
| Side | 22 ° |
| Rear | 8 ° |
