Hamm
3410P
Padfoot Compactor
31 specifications
1 / 5
Image 1 of 5
Specifications
25 data points
Operating Specifications
| Operating Weight | 29,377 lb |
|---|---|
| Max Speed | 7.9 mph |
| Fuel Capacity | 104.9 gal |
| Operating Width | 89 in |
Engine
| Engine Model | 6BT5.9C |
|---|---|
| Displacement | 359 in³ |
| Gross Power | 130.1 hp |
| Aspiration | turbocharged |
| Make | Cummins |
Dimensions
| Ground Clearance | 18 in |
|---|---|
| Height - Top of Cab | 128 in |
| Wheelbase | 10 in |
| Turning Radius - Inside | 142 in |
| Overall Length w/o Blade | 233 in |
Tires & Wheels
| Tires | 23.1x20-26 8PR |
|---|
Drum
| Drum Width | 83 in |
|---|---|
| Vibration Frequency 1 | 29 vpm |
| Centrifugal Force - High | 29,450 lb |
| Drum Diameter | 55 in |
| Nominal Amplitude - High | 0 in |
| Pad Height | 4 in |
| Number of Pads | 132 |
| Vibratory Frequency 2 | 35 vpm |
| Pad Surface Area | 24 in³ |
| Vibration Frequency | — |
