Vogele
SUPER 2500
- Operating Weight w/ Screed
- 60,848 lb
- Paving Width - max
- 374 in
- Gross Power
- 366.1 hp
- Length w/ Screed
- 280 in
1 / 5
Image 1 of 5
Specifications
20 data points
Operating Specifications
| Operating Weight w/ Screed | 60,848 lb |
|---|---|
| Fuel Capacity | 107.0 gal |
| Operating Voltage | 24 V |
Engine
| Engine Model | TCD 2015 V6 |
|---|---|
| Power Measured @ | 1,800 rpm |
| Gross Power | 366.1 hp |
| Number of Cylinders | 6 |
| Make | Deutz |
Dimensions
| Length of Track on Ground | 131 in |
|---|---|
| Transport Height | 148 in |
| Track Width | 16 in |
| Length w/ Screed | 280 in |
| Width w/ Hopper Open | 157 in |
| Length w/o Screed | 228 in |
Hopper/Paver
| Paving Width - max | 374 in |
|---|---|
| Paving Speed - max | 0.7 mph |
| Hopper Capacity | 19 lb |
| Travel Speed - max | 2.0 mph |
| Auger Diameter | 19 in |
| Paving Thickness - max | 16 in |
