Volvo
Terex
TA27
Off-Highway Truck
46 specifications
1 / 5
Image 1 of 5
Specifications
57 data points
Operating Specifications
| Tire Size | 29.5R25 |
|---|
Engine
| Engine Model | D13J |
|---|---|
| Gross Power | 469.0 hp |
| Net Power | 465.0 hp |
| Torque Measured @ | 1,050 rpm |
| Max Torque | 1,862 lb-ft |
| Make | Volvo |
Weights
| Operating Weight | 153,662 lb |
|---|---|
| Total Empty | 65,918 lb |
| Total Loaded | 151,899 lb |
Dimensions
| Ground Clearance | 25 in |
|---|---|
| Wheelbase | 122 in |
| Overall Length | 444 in |
| Overall Width | 230 in |
| Overall Height | 143 in |
| Dump Height | 287 in |
| Dump Ground Clearance | 32 in |
Transmission
| Max Speed | 35.5 mph |
|---|---|
| Transmission Type | Auto |
| Number of Forward Gears | 9 |
| Number of Reverse Gears | 3 |
Fluid Capacities
| Fuel Tank | 126.9 gal |
|---|---|
| Hydraulic Tank | 46.0 gal |
| Cooling system | 11.7 gal |
| Transmission | 11.4 gal |
| DEF Tank | 10.4 gal |
| Dropbox | 2.4 gal |
| Brake cooling system | 49.7 gal |
| Crankcase | 13.3 gal |
General Specifications
| Operating Weight lbs (kg) | 153,662 (69,700) Starting 2024 Model Year |
|---|---|
| Engine type | Volvo D13J Starting 2019 Model Year |
| Articulated/Rigid | Articulated Starting 2024 Model Year |
| Drive Configuration | 6x4 and 6x6 Starting 2019 Model Year |
| Rated Payload Tons (Metric Tons) | 43 (39) Starting 2019 Model Year |
| Mfg. Model | A40G Starting 2019 Model Year |
| Drive System Mech/Electr. | M Starting 2019 Model Year |
Drive System
| Drive Config | 6x6 |
|---|---|
| Transmission | PT 2529 |
| Axles | ARB H40 |
| Dropbox | IL2 ATC |
| Torque converter | 2.1:1 |
Articulating/Rigid
| Articulating/Rigid | Articulated |
|---|
Dump
| Rated Payload | 94,799 lb |
|---|---|
| Dump Angle | 70 ° |
| Raise Time | 22.0 s |
| Lower Time | 22.0 s |
| Capacity - Heaped | 31.40 yd³ |
| Capacity - Struck | 24.11 yd³ |
Electrical System
| Alternator | — |
|---|---|
| Starter motor | 9 |
| Battery | 2x12 |
| Battery capacity | — |
| Voltage | — |
Body
| Plate thickness-Front | 0 in |
|---|---|
| Plate thickness-Bottom | 1 in |
| Plate thickness-Chute | 1 in |
| Plate thickness-Sides | 1 in |
