Volvo
Tata Hitachi
TWL3036
Wheel Loader
41 specifications
1 / 5
Image 1 of 5
Specifications
37 data points
Operating Specifications
| Operating Weight | 25,400 lb |
|---|---|
| Fuel Capacity | 50.2 gal |
| Tire Size | 20.5R25 |
| Hydraulic System Fluid Capacity | 17.2 gal |
| Static Tipping Weight | 39,022 lb |
| Operating Voltage | 24 V |
| Rear Axle Oscillation | 26 ° |
| Alternator Supplied Amperage | 60 A |
Engine
| Engine Model | TD 61 GD |
|---|---|
| Displacement | 335 in³ |
| Power Measured @ | 2,200 rpm |
| Net Power | 118.0 hp |
| Number of Cylinders | 6 |
| Aspiration | turbocharged |
| Torque Measured @ | 1,200 rpm |
Hydraulic System
| Pump Flow Capacity | 42.3 gal/min |
|---|---|
| Raise Time | 5.1 s |
| Lower Time | 3.0 s |
| Dump Time | 1.3 s |
| Relief Valve Setting | 3,770 psi |
| Pump Type | load sensing |
Dimensions
| Ground Clearance | 18 in |
|---|---|
| Height - Top of Cab | 126 in |
| Wheelbase | 113 in |
| Width Over Tires | 95 in |
| Reach at Max Lift and Dump | 36 in |
| Length with Bucket on Ground | 265 in |
| Hinge Pin - Max Height | 152 in |
Transmission
| Max Speed - Forward | 27.4 mph |
|---|---|
| Max Speed - Reverse | 16.2 mph |
| Transmission Type | powershift |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 3 |
Bucket
| Bucket Capacity - heaped | 1.80 yd³ |
|---|---|
| Dump Clearance at Max Raise | 118 in |
| Breakout Force | 22,700 lb |
| Bucket Width | 100 in |
