Volvo
Komatsu
PC20R-8
Mini Excavator
47 specifications
1 / 5
Image 1 of 5
Specifications
48 data points
Operating Specifications
| Operating Weight | 7,355 lb |
|---|---|
| Fuel Capacity | 13.0 gal |
| Hydraulic Pump Flow Capacity | 24.9 gal/min |
| Hydraulic System Fluid Capacity | 12.7 gal |
| Hydraulic System Relief Valve Pressure | 3,483 psi |
| Operating Voltage | 12 V |
| Alternator Supplied Amperage | 40 A |
| Engine Oil Capacity | 1.9 gal |
| Cooling System Fluid Capacity | 1.4 gal |
Engine
| Engine Model | D1.6 |
|---|---|
| Displacement | 100 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 27.6 hp |
| Net Power | 27.0 hp |
| Number of Cylinders | 3 |
| Aspiration | Natural |
| Torque Measured @ | 1,300 rpm |
| Max Torque | 76 lb-ft |
Dimensions
| Ground Clearance | 12 in |
|---|---|
| Height - Top of Cab | 97 in |
| Length of Track on Ground | 64 in |
| Tail Swing Radius | 32 in |
| Width to Outside of Tracks | 65 in |
| Removal Counterweight Clearance | 24 in |
Undercarriage
| Ground Pressure | 4 psi |
|---|---|
| Track Gauge | 53 in |
| Number of Track Rollers per Side | 4 |
| Max Travel Speed | 2.4 mph |
| Shoe Size | 12 in |
| Number of Carrier Rollers per Side | 1 |
Boom/Stick Excavator Option 1
| Max Digging Depth | 108 in |
|---|---|
| Max Reach Along Ground | 190 in |
| Max Vertical Wall Digging Depth | 101 in |
| Max Loading Height | 126 in |
| Shipping Length of Unit | 175 in |
| Max Cutting Height | 175 in |
| Shipping Height of Unit | 97 in |
Bucket
| Reference Bucket Capacity | 0.20 yd³ |
|---|---|
| Maximum Bucket Capacity | 0.30 yd³ |
| Minimum Bucket Capacity | 0.10 yd³ |
Swing Mechanism
| Swing Speed | 10 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 119 in |
|---|---|
| Max Cutting Height | 180 in |
| Max Loading Height | 132 in |
| Max Vertical Wall Digging Depth | 110 in |
| Max Reach Along Ground | 203 in |
| Shipping Height of Unit | 97 in |
| Shipping Length of Unit | 175 in |
