Volvo
Komatsu
PC20R-8
Mini Excavator
47 specifications
1 / 5
Image 1 of 5
Specifications
56 data points
Operating Specifications
| Operating Weight | 6,012 lb |
|---|---|
| Fuel Capacity | 13.0 gal |
Engine
| Engine Model | D2.6H |
|---|---|
| Displacement | 160 in³ |
| Power Measured @ | 2,200 rpm |
| Gross Power | 58.0 hp |
| Net Power | 55.0 hp |
| Number of Cylinders | 4 |
| Max Torque | 162 lb-ft |
| Bore | 0 in |
| Stroke | 0 in |
| Max Power | — |
| Rated Engine Speed | 1,300 rpm |
| Fuel tank | 7.7 gal |
Hydraulic System
| Main pump - Maximum flow | — |
|---|
Dimensions
| Height - Top of Cab | 108 in |
|---|---|
| Overall Length | 251 in |
| Overall Width | 91 in |
| Tail Swing Radius | 52 in |
| Track Gauge | 73 in |
| Counterweight Clearance | 30 in |
| Shoe width | 18 in |
| Track length | 112 in |
Undercarriage
| Drawbar Pull | 14,613 lb |
|---|---|
| Number of bottom rollers per side | — |
| Number of top rollers per side | — |
| Shoe Width - Steel | 450/600 in (177/236 mm) |
| Shoe width - rubber | 18 in |
Fluid Capacities
| Hydraulic system | 9.8 gal |
|---|---|
| Engine Oil | 2.7 gal |
| Hydraulic Tank | 5.9 gal |
| Travel reduction | 0.9 gal |
Boom/Stick Excavator Option 1
| Max Digging Depth | 163 in |
|---|---|
| Max Reach Along Ground | 289 in |
| Max Vertical Wall Digging Depth | 111 in |
| Max Cutting Height | 268 in |
| Max.Dumping Height | 196 in |
| Max Digging Reach | 275 in |
| Max Digging Reach on Ground | 269 in |
Bucket
| Reference Bucket Capacity | 0.50 yd³ |
|---|
General Specifications
| Operating Weight lbs (kg) | 19,300 (8,810) — Starting 2025 Model Year |
|---|---|
| Digging Depth ft (m) | 14.9 (4.5) — Starting 2025 Model Year |
| Engine hp (kW) | 58 (43) — Starting 2025 Model Year |
| Digging Reach ft. (m) | 23.7 (7.2) — Starting 2025 Model Year |
Loader
| Breakout Force | — |
|---|
Swing Mechanism
| Swing Speed | 9 rpm |
|---|---|
| Swing Torque | 16,890 lb-ft |
Boom/Stick Excavator Option 2
| Max Digging Depth | 179 in |
|---|---|
| Max Cutting Height | 278 in |
| Max Vertical Wall Digging Depth | 126 in |
| Max.Dumping Height | 206 in |
| Max Digging Reach | 291 in |
| Max Digging Reach on Ground | 283 in |
Electrical System
| Voltage | 12 V |
|---|---|
| Battery | 100(Ah) |
Performance
| Gradeability | 35.0 % |
|---|
