Volvo
New Holland
E200SR
Excavator
44 specifications
1 / 5
Image 1 of 5
Specifications
62 data points
Operating Specifications
| Operating Weight | 33,951 lb |
|---|---|
| Fuel Capacity | 66.1 gal |
| Hydraulic Pump Flow Capacity | 60.8 gal/min |
| Hydraulic System Fluid Capacity | 62.1 gal |
| Hydraulic System Relief Valve Pressure | 5,221 psi |
| Engine Oil Capacity | 4.0 gal |
| Cooling System Fluid Capacity | 5.7 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 80 A |
| Hydraulic Pump Type | axial piston |
| Tire Size | 10.00-20 |
Engine
| Engine Model | D5D EBE2 |
|---|---|
| Displacement | 293 in³ |
| Power Measured @ | 1,900 rpm |
| Gross Power | 123.0 hp |
| Net Power | 118.0 hp |
| Number of Cylinders | 4 |
| Aspiration | turbocharged |
| Torque Measured @ | 1,400 rpm |
| Net Torque | 409 lb-ft |
Dimensions
| Ground Clearance | 13 in |
|---|---|
| Height - Top of Cab | 124 in |
| Wheelbase | 103 in |
| Overall Width | 8 in |
| Tail Swing Radius | 79 in |
| Overall Width - Outriggers Down | 155 in |
Transmission
| Max Travel Speed | 18.7 mph |
|---|---|
| Transmission Type | powershift |
| Number of Forward Gears | 2 |
| Number of Reverse Gears | 2 |
Bucket
| Reference Bucket Capacity | 0.80 yd³ |
|---|---|
| Maximum Bucket Capacity | 0.99 yd³ |
| Minimum Bucket Capacity | 0.30 yd³ |
Swing Mechanism
| Swing Speed | 10 rpm |
|---|
Boom/Stick Mobile Excavator Option 1
| Max Digging Depth | 198 in |
|---|---|
| Max Cutting Height | 340 in |
| Max Reach Along Ground | 324 in |
| Max Loading Height | 233 in |
| Shipping Length of Unit | 296 in |
| Shipping Height of Unit | 133 in |
| Max Vertical Wall Dig Depth | 174 in |
Boom/Stick Mobile Excavator Option 2
| Max Digging Depth | 217 in |
|---|---|
| Max Cutting Height | 350 in |
| Max Reach Along Ground | 347 in |
| Max Loading Height | 248 in |
| Shipping Height of Unit | 133 in |
| Shipping Length of Unit | 299 in |
| Max Vertical Wall Dig Depth | 193 in |
Boom/Stick Mobile Excavator Option 3
| Max Digging Depth | 198 in |
|---|---|
| Max Cutting Height | 378 in |
| Max Reach Along Ground | 331 in |
| Max Loading Height | 269 in |
| Shipping Height of Unit | 124 in |
| Shipping Length of Unit | 306 in |
| Max Vertical Wall Dig Depth | 138 in |
Boom/Stick Mobile Excavator Option 4
| Max Digging Depth | 226 in |
|---|---|
| Max Cutting Height | 390 in |
| Max Reach Along Ground | 359 in |
| Max Loading Height | 288 in |
| Shipping Height of Unit | 124 in |
| Shipping Length of Unit | 263 in |
| Max Vertical Wall Dig Depth | 162 in |
