Specifications
63 data points
Operating Specifications
| Operating Weight | 42,946 lb |
|---|---|
| Fuel Capacity | 66.1 gal |
| Hydraulic Pump Flow Capacity | 105.0 gal/min |
| Hydraulic System Fluid Capacity | 79.3 gal |
| Hydraulic System Relief Valve Pressure | 5,220 psi |
| Engine Oil Capacity | 6.7 gal |
| Cooling System Fluid Capacity | 6.7 gal |
| Operating Voltage | 24 V |
| Alternator Supplied Amperage | 80 A |
| Hydraulic Pump Type | high flow electronically controlled |
| Tire Size | 10.00-20 |
| Oscillating Axle Angle | 9 ° |
| Front Diff Fluid Capacity | 2.6 gal |
| Rear Diff Fluid Capacity | 3.4 gal |
Engine
| Engine Model | D6E ECE3 |
|---|---|
| Displacement | 348 in³ |
| Power Measured @ | 1,900 rpm |
| Gross Power | 164.0 hp |
| Net Power | 152.0 hp |
| Number of Cylinders | 6 |
| Aspiration | turbocharged |
| Torque Measured @ | 1,350 rpm |
| Net Torque | 538 lb-ft |
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Height - Top of Cab | 126 in |
| Wheelbase | 104 in |
| Overall Width | 8 in |
| Tail Swing Radius | 97 in |
| Upper Structure Clearance | 52 in |
| Overall Width - Outriggers Down | 159 in |
Transmission
| Max Travel Speed | 21.8 mph |
|---|---|
| Transmission Type | powershift |
Bucket
| Reference Bucket Capacity | 1.10 yd³ |
|---|
Swing Mechanism
| Swing Speed | 10 rpm |
|---|---|
| Swing Torque | 45,983 lb-ft |
Boom/Stick Mobile Excavator Option 1
| Max Digging Depth | 223 in |
|---|---|
| Max Cutting Height | 359 in |
| Max Reach Along Ground | 353 in |
| Max Loading Height | 253 in |
| Shipping Length of Unit | 344 in |
| Shipping Height of Unit | 115 in |
| Max Vertical Wall Dig Depth | 154 in |
Boom/Stick Mobile Excavator Option 2
| Max Digging Depth | 229 in |
|---|---|
| Max Cutting Height | 361 in |
| Max Reach Along Ground | 357 in |
| Max Loading Height | 254 in |
| Shipping Height of Unit | 124 in |
| Shipping Length of Unit | 346 in |
| Max Vertical Wall Dig Depth | 158 in |
Boom/Stick Mobile Excavator Option 3
| Max Digging Depth | 246 in |
|---|---|
| Max Cutting Height | 369 in |
| Max Reach Along Ground | 373 in |
| Max Loading Height | 263 in |
| Shipping Height of Unit | 139 in |
| Shipping Length of Unit | 347 in |
| Max Vertical Wall Dig Depth | 173 in |
Boom/Stick Mobile Excavator Option 4
| Max Digging Depth | 227 in |
|---|---|
| Max Cutting Height | 398 in |
| Max Reach Along Ground | 360 in |
| Max Loading Height | 284 in |
| Shipping Height of Unit | 121 in |
| Shipping Length of Unit | 350 in |
| Max Vertical Wall Dig Depth | 169 in |
