Volvo
JCB
JS240L
Excavator
13 specifications
.jpg)
1 / 5
Image 1 of 5
Specifications
67 data points
Operating Specifications
| Operating Weight | 43,430 lb |
|---|
Engine
| Engine Model | D6H |
|---|---|
| Displacement | 348 in³ |
| Gross Power | 129.0 hp |
| Number of Cylinders | 6 |
| Torque Measured @ | 1,500 rpm |
| Stroke | 5 in |
| Bore | 4 in |
| Max Power | — |
| Net Torque | 758 lb-ft |
Hydraulic System
| Implement | 5,440 psi |
|---|---|
| Main pump- low noise axial piston pump-MAX Flow | 111.0 gal/min |
| Pilot circuit | 490 psi |
| Maximum flow -Servo pump, low noise gear pump | 4.2 gal/min |
| Steering pump | 10.0 gal/min |
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Height - Top of Cab | 126 in |
| Wheelbase | 109 in |
| Overall Width | 108 in |
| Tail Swing Radius | 104 in |
| Counterweight Clearance | 50 in |
Fluid Capacities
| Fuel Tank | 88.5 gal |
|---|---|
| Engine Oil | 6.7 gal |
| Hydraulic Tank | 43.6 gal |
| Transmission | 6.7 gal |
| Engine coolant | 8.8 gal |
| Final Drive | 26.5 gal |
| Front axle | 5,797 in³ |
| Rear Axle | 38.4 gal |
Boom/Stick Excavator Option 1
| Max Reach Along Ground | 391 in |
|---|---|
| Max Vertical Wall Digging Depth | 174 in |
| Max Cutting Height | 370 in |
| Max Digging Reach | 380 in |
| Max.Dumping Height | 259 in |
| Max Digging Reach on Ground | 373 in |
| Boom/Stick Option (HEX) 1 | MoonBoom 59 mm(Ftin-184)Arm 245 mm(Ftin-80 |
| Min - front slew radius | 142 in |
Swing Mechanism
| Swing Speed | 10 rpm |
|---|---|
| Swing Torque | 572 lb-ft |
Boom/Stick Excavator Option 2
| Max Digging Depth | 250 in |
|---|---|
| Max Vertical Wall Digging Depth | 179 in |
| Max Cutting Height | 372 in |
| Max Digging Reach | 385 in |
| Max.Dumping Height | 261 in |
| Max Digging Reach on Ground | 373 in |
| Boom/Stick Option (HEX) 2 | MoonBoom 59 mm(Ftin-184)Arm 26 mm(Ftin-86) |
| Min - front slew radius | 142 in |
Boom/Stick Excavator Option 3
| Max Digging Depth | 248 in |
|---|---|
| Max Cutting Height | 378 in |
| Max Vertical Wall Digging Depth | 190 in |
| Max.Dumping Height | 268 in |
| Max Digging Reach on Ground | 389 in |
| Boom/Stick Option (HEX) 3 | MoonBoom 59 mm(Ftin-184)Arm 29 mm(Ftin-96) |
| Max Digging Reach | 396 in |
| Min - front slew radius | 141 in |
Boom/Stick Excavator Option 4
| Max Digging Depth | 211 in |
|---|---|
| Max Cutting Height | 340 in |
| Max Digging Reach | 350 in |
| Boom/Stick Option (HEX) 4 | MoonBoom 59 mm(Ftin-184)Arm 32 mm(Ftin-106) |
| Min - front slew radius | 163 in |
Electrical System
| Alternator | — |
|---|---|
| Voltage | 24 V |
| Battery capacity | 100 Ah |
Speeds
| creep | 2.0 mph |
|---|---|
| Min turning radius | 319 in |
| speed -off road | 4.6 mph |
| speed -on road | 18.5 mph |
