Volvo
Michigan
L320
Wheel Loader
45 specifications
1 / 5
Image 1 of 5
Specifications
57 data points
Operating Specifications
| Fuel Capacity | 153.5 gal |
|---|---|
| Hydraulic System Fluid Capacity | 96.5 gal |
| Engine Oil Fluid Capacity | 14.6 gal |
| Cooling System Fluid Capacity | 18.0 gal |
| Transmission Fluid Capacity | 20.9 gal |
| Rated Bucket Capacity | 8.59 – 16.60 yd³ |
| DEF tank capacity | 14.1 gal |
Engine
| Engine Model | Volvo D16J |
|---|---|
| Displacement | 983 in³ |
| Power Measured @ | 1,700 rpm |
| Gross Power | 532.0 hp |
| Net Power | 528.0 hp |
| Number of Cylinders | 6 |
| Aspiration | VGT (Variable Geometry Turbocharged) |
| Torque Measured @ | 1,400 rpm |
Weights
| Operating Weight | 116,460 lb |
|---|
Hydraulic System
| Working pressure | Pump 1 - 25 MPa Pump 2 - 26 MPa Pump 3 - 26 MPa |
|---|---|
| Engine speed | 1,800 rpm |
Dimensions
| Ground Clearance | 23 in |
|---|---|
| Height - Top of Cab | 166 in |
| Wheelbase | 170 in |
| Width Over Tires | 144 in |
| Reach at Max Lift and Dump | 74 in |
| Length with Bucket on Ground | 442 in |
| Hinge Pin - Max Height | 210 in |
Bucket
| Dump Clearance at Max Raise | 143 in |
|---|---|
| Breakout Force | 100,152 lb |
| Bucket Width | 157 in |
General Specifications
| Operating Weight | 115,730 (52,490) Starting 2024 Model Year |
|---|---|
| Bucket Capacity | 9.5 (7.3) Starting 2024 Model Year |
| Engine type | Volvo D16J (Tier 4F) Starting 2024 Model Year |
| Engine Power | 528 (394) Starting 2019 Model Year |
| Max Dump Height | 11 (3.7) Starting 2024 Model Year |
Drive System
| Transport speed, maximum | 23.7 mph |
|---|---|
| Torque multiplication, stall ratio | 2.65 |
| Transmission | Volvo HTE 400 |
Hydraulic cycle times (unloaded)
| Total cycle time | 14.6 s |
|---|---|
| Lift | 8.0 s |
| Lower | 4.7 s |
| Tilt | 1.9 s |
Steering System
| Articulation Angle | 37 ° |
|---|---|
| Maximum flow | 89.9 gal/min |
| Steering cylinders | 2 |
| Working pressure | 26 MPa 260 bar |
| Cylinder bore | 4 in |
| Rod diameter | 3 in |
| Stroke | 24 in |
Electrical System
| Voltage | 24 V |
|---|---|
| Battery capacity | — |
| Alternator rating | 2280/80 (W/A) |
| Starter motor output | 9.4 hp |
| Cold cranking capacity | 1000 A |
Axles
| Front | Volvo AHW 90 |
|---|---|
| Rear | Volvo AHW 90 |
| Axle oil front | 41.0 gal |
| Axle oil rear | 41.0 gal |
| Rear axle oscillation | 12 ° |
