Volvo
New Holland
W110B
Wheel Loader
43 specifications
1 / 5
Image 1 of 5
Specifications
29 data points
Operating Specifications
| Operating Weight | 17,000 lb |
|---|---|
| Fuel Capacity | 29.1 gal |
| Tire Size | front 16.9-30/14 rear 12.4-24/12 |
| Hydraulic System Fluid Capacity | 23.8 gal |
| Operating Voltage | 24 V |
| Turning Radius | 221 in |
Engine
| Engine Model | BM- D 42 |
|---|---|
| Displacement | 256 in³ |
| Power Measured @ | 2,300 rpm |
| Gross Power | 80.0 hp |
| Number of Cylinders | 4 |
| Aspiration | direct injection |
| Torque Measured @ | 1,300 rpm |
Hydraulic System
| Pump Flow Capacity | 38.4 gal/min |
|---|---|
| Relief Valve Setting | 1,422 psi |
| Pump Type | Hamworthy |
Dimensions
| Ground Clearance | 15 in |
|---|---|
| Height - Top of Cab | 104 in |
| Wheelbase | 94 in |
| Reach at Max Lift and Dump | 30 in |
| Length with Bucket on Ground | 220 in |
| Hinge Pin - Max Height | 152 in |
Transmission
| Max Speed - Forward | 18.7 mph |
|---|---|
| Max Speed - Reverse | 18.7 mph |
| Transmission Type | full powershift |
| Number of Forward Gears | 4 |
| Number of Reverse Gears | 4 |
Bucket
| Bucket Capacity - heaped | 1.29 yd³ |
|---|---|
| Dump Clearance at Max Raise | 115 in |
