Wacker Neuson
JCB
8010 CTS
Mini Excavator
34 specifications
1 / 5
Image 1 of 5
Specifications
25 data points
Operating Specifications
| Operating Weight | 2,401 lb |
|---|---|
| Fuel Capacity | 1.8 gal |
| Hydraulic Pump Flow Capacity | 2.8 gal/min |
| Hydraulic System Fluid Capacity | 3.7 gal |
| Hydraulic System Relief Valve Pressure | 2,466 psi |
Engine
| Engine Model | 3TNV74F |
|---|---|
| Displacement | 61 in³ |
| Power Measured @ | 2,500 rpm |
| Net Power | 15.4 hp |
| Number of Cylinders | 3 |
| Aspiration | Water-cooled |
| Engine Make | Yanmar |
Dimensions
| Ground Clearance | 6 in |
|---|---|
| Height - Top of Cab | 56 in |
| Length of Track on Ground | 111 in |
| Tail Swing Radius | 30 in |
| Width to Outside of Tracks | 35 in |
Undercarriage
| Max Travel Speed | 1.1 mph |
|---|
Boom/Stick Excavator Option 1
| Max Digging Depth | 70 in |
|---|---|
| Max Reach Along Ground | 120 in |
| Max Vertical Wall Digging Depth | 53 in |
| Max Loading Height | 79 in |
| Shipping Length of Unit | 111 in |
| Max Cutting Height | 113 in |
| Shipping Height of Unit | 56 in |
