Wacker Neuson
Case
21D
Wheel Loader
43 specifications
1 / 5
Image 1 of 5
Specifications
36 data points
Operating Specifications
| Max Speed | 12.4 mph |
|---|---|
| Tire Size | 15/55-18 EM ET 0 |
| Operating Voltage | 12 V |
Engine
| Engine Model | TCD 2.9 L4 |
|---|---|
| Displacement | 135 in³ |
| Power Measured @ | 2,600 rpm |
| Gross Power | 74.0 hp |
| Number of Cylinders | 4 |
| Engine Make | Deutz |
| Alternator | 85 A |
Weights
| Operating Weight | 9,259 lb |
|---|---|
| Breakout force maximum | 9,280 lb-ft |
| Lifting force maximum | 4,850 lb |
Hydraulic System
| Pump Flow Capacity | 14.6 gal/min |
|---|---|
| Relief Valve Pressure | 6,454 psi |
Dimensions
| Ground Clearance | 13 in |
|---|---|
| Height - Top of Cab | 100 in |
| Wheelbase | 81 in |
| Overall Length | 203 in |
| Width Over Tires | 62 in |
| Length with Bucket on Ground | 169 in |
| Turning Radius | 65 in |
Fluid Capacities
| Fuel Tank | 17.2 gal |
|---|---|
| Hydraulic oil tank | 13.3 gal |
Bucket
| Bucket Capacity - heaped | 0.80 yd³ |
|---|---|
| Dumping angle, top | 42 ° |
General Specifications
| Operating Weight | 9,480 (4,300) Starting 2024 Model Year |
|---|---|
| Operating Weight lbs (kg) | 9,480 (4,300) Starting 2025 Model Year |
| Bucket Capacity | 0.75 (.57) Starting 2024 Model Year |
| Bucket Capacity cu. yd. (cu m) | 0.75 (.57) Starting 2025 Model Year |
| Engine type | Deutz TCD 2.9 L4 Starting 2024 Model Year |
| Engine Power | 74 (55) Starting 2024 Model Year |
| Max Dump Height | 8.0 (2.44) Starting 2024 Model Year |
| Max Dump Height ft.( m) | 8.0 (2.44) Starting 2025 Model Year |
| OperatingWeight lbs. (kg) | 9,480 (4,300) Starting 2026 Model Year |
| Engine Power Gross hp (kW) | 74 (55) Starting 2025 Model Year |
