Zoomlion

PY215

Motor Grader

Max Power
215.0 hp
All motor graders
Zoomlion PY215 Motor Grader
1 / 5
Image 1 of 5
Image: hngmie.en.made-in-china.com

Specifications

17 data points

Operating Specifications

Operating Specifications specifications
Std Operation Weight - Total35,935 lb
Fuel Capacity79.3 gal
Hydraulic System Fluid Capacity31.8 gal
Circle Gearbox Fluid Capacity7.4 gal

Engine

Engine specifications
Engine Model6CTA8.3-C215
Power Measured @2,200 rpm
Max Power215.0 hp

Dimensions

Dimensions specifications
Overall Length359 in
Width Over Tires103 in
Height to Top of Isomount Cab130 in

Transmission

Transmission specifications
Max Speed - Forward24.9 mph
Max Speed - Reverse15.6 mph

Moldboard

Moldboard specifications
Moldboard Height24 in
Moldboard Width169 in
Max Depth of Cut20 in

Circle

Circle specifications
Max Lift Above Ground18 in

Steering System

Steering System specifications
Turning Radius312 in
