Case
Kobelco
SK350LC-10 H&W
Excavator
35 specifications
1 / 5
Image 1 of 5
Specifications
70 data points
Operating Specifications
| Operating Weight | 63,524 lb |
|---|---|
| Arm Breakout Force | 8,992 lb |
| Arm size | 314,962 in |
Engine
| Engine Model | Isuzu 4 HKIX |
|---|---|
| Displacement | 317 in³ |
| Power Measured @ | 2,000 rpm |
| Net Power | 177.0 hp |
| Max Torque | 458 lb-ft |
| Engine Make | Isuzu |
| Bore | 5 in |
| Stroke | 5 in |
| Fuel Type | Requires ultra-low sulfur fuel B5 biodiesel tolerant |
| Emission Tier Level | Tier 4 |
| Fuel injection | Direct injection - electronic |
| Air filter type | Dry type element with warning restriction indicator |
| Fuel Filter | Replaceable full flow spin-on cartridge |
| Oil Filter | Replaceable full flow spin-on cartridge |
Hydraulic System
| Main pump - Maximum flow | 123.7 gal |
|---|---|
| System relief pressure | 50 psi |
Dimensions
| Tail Swing Radius | 117 in |
|---|---|
| Overall Height | 121 in |
| Track Shoe Width | 32 in |
| Cab height | 132 in |
| Overall length (L/bucket) | 390 in |
| Center to center - idler to sprocket | 151 in |
| Ground pressure | 6 psi |
| Boom length | 1 in |
| Overall Track Length | 183 in |
| Minimum ground clearance | 17 in |
Transmission
| Max Speed | 3.5 mph |
|---|
Undercarriage
| Track Shoe Width | 32 in |
|---|
Brakes & Steering
| Service brake | SAHR disc - each motor |
|---|---|
| Brakes Type | Mechanical disc |
| Travel control | Dual stage relief or counter balance design |
Fluid Capacities
| Fuel Tank | 108.4 gal |
|---|---|
| Hydraulic system | 66.1 gal |
| Hydraulic Tank | 38.9 gal |
| Cooling system | 8.3 gal |
| Engine oil w/ filter change | 6.2 gal |
| Swing drive | 2.6 gal |
| Final Drive | 1.4 gal |
| DEF Tank | 31.8 gal |
Boom/Stick Excavator Option 1
| Max Digging Depth | 574 in |
|---|---|
| Max Reach Along Ground | 398 in |
| Minimum swing radius | 159 in |
| Max.Dumping Height | 465 in |
| Max Digging Reach on Ground | 718 in |
| Bucket rotation | 175 ° |
| Mximum dig radius | 405 in |
| Dig radius at ground line | 398 in |
| Dump height | 266 in |
| Maximum vertical wallcut depth | 243 in |
Swing Mechanism
| Swing Speed | 11 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Vertical Wall Digging Depth | 226 in |
|---|---|
| Minimum swing radius | 157 in |
| Bucket rotation | 175 ° |
| Dig radius at ground line | 379 in |
| Dump height | 258 in |
| Maximum dig radius | 387 in |
Boom/Stick Excavator Option 3
| Max Vertical Wall Digging Depth | 264 in |
|---|---|
| Minimum swing radius | 160 in |
| Overall height | 121 in |
| Bucket rotation | 175 ° |
| Maximum dig radius | 425 in |
| Dig radius at ground line | 418 in |
| Dump height | 278 in |
Performance
| Lift over end Max. reach | 40,168 lb |
|---|---|
| Lift over side Max. reach | 2,094 lb |
| Lift over end 10' radius | 3,285 lb |
| Lift over side 10' radius | 31,769 lb |
