Case
Kobelco
SK350LC-10 H&W
Excavator
35 specifications
1 / 5
Image 1 of 5
Specifications
65 data points
Operating Specifications
| Operating Weight | 66,478 lb |
|---|---|
| Arm Breakout Force | 31,473 lb |
| Arm size | 125,197 in |
Engine
| Engine Model | Isuzu 6 HK1X |
|---|---|
| Displacement | 476 in³ |
| Power Measured @ | 1,800 rpm |
| Net Power | 154.0 hp |
| Max Torque | 626 lb-ft |
| Engine Make | Isuzu |
| Bore | 5 in |
| Stroke | 5 in |
| Fuel Type | Requires ultra low-sulfur fuel B5 biodiesel tolerant |
| Emission Tier Level | Tier 4 |
| Fuel injection | Direct injection - electronic |
| Air filter type | Dry type element w/ warning restriction indicator |
| Fuel Filter | Replaceable full flow spin-on cartridge |
| Oil Filter | Replaceable full flow spin-on cartridge |
Hydraulic System
| Main pump - Maximum flow | 128.4 gal |
|---|---|
| System relief pressure | 50 psi |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Tail Swing Radius | 125 in |
| Ground pressure | 6 psi |
| Boom length | 1 in |
Transmission
| Max Speed | 3.4 mph |
|---|
Undercarriage
| Track Shoe Width | 32 in |
|---|
Brakes & Steering
| Service brake | Mechanical disc |
|---|---|
| Brakes Type | Dual stage relief or counter balance design |
| Travel control | SAHR disc - each motor |
Fluid Capacities
| Fuel Tank | 120.8 gal |
|---|---|
| Hydraulic system | 79.3 gal |
| Hydraulic Tank | 38.9 gal |
| Cooling system | 9.5 gal |
| Engine oil w/ filter change | 10.9 gal |
| Swing drive | 0.4 gal |
| Final Drive | 2.6 gal |
| DEF Tank | 31.8 gal |
Boom/Stick Excavator Option 1
| Max Digging Depth | 280 in |
|---|---|
| Max Reach Along Ground | 414 in |
| Max Vertical Wall Digging Depth | 241 in |
| Minimum swing radius | 159 in |
| Max.Dumping Height | 280 in |
| Bucket rotation | 176 ° |
| Mximum dig radius | 420 in |
| Dig radius at ground line | 413 in |
| Dump height | 279 in |
Swing Mechanism
| Swing Speed | 10 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 259 in |
|---|---|
| Max Vertical Wall Digging Depth | 227 in |
| Minimum swing radius | 157 in |
| Bucket rotation | 176 ° |
| Dig radius at ground line | 395 in |
| Dump height | 273 in |
| Maximum dig radius | 402 in |
| Maximum reach height | 391 in |
Boom/Stick Excavator Option 3
| Max Digging Depth | 299 in |
|---|---|
| Minimum swing radius | 161 in |
| Bucket rotation | 176 ° |
| Maximum dig radius | 439 in |
| Dig radius at ground line | 432 in |
| Dump height | 291 in |
| Maximum reach height | 409 in |
Performance
| Lift over end Max. reach | 9,348 lb |
|---|---|
| Lift over side Max. reach | 7,033 lb |
| Lift over end 10' radius | 19,379 lb |
| Lift over side 10' radius | 19,379 lb |
