Case
Kobelco
SK350LC-10 H&W
Excavator
35 specifications
1 / 5
Image 1 of 5
Specifications
58 data points
Operating Specifications
| Operating Weight | 78,043 lb |
|---|---|
| Fuel Capacity | 153.0 gal |
| Hydraulic Pump Flow Capacity | 150.1 gal/min |
| Hydraulic System Fluid Capacity | 92.0 gal |
| Hydraulic System Relief Valve Pressure | 4,975 psi |
| Engine Oil Capacity | 9.5 gal |
| Cooling System Fluid Capacity | 8.0 gal |
| Operating Voltage | 24 V |
| Swing Drive Fluid Capacity | 1.6 gal |
| Alternator Supplied Amperage | 50 A |
Engine
| Engine Model | AH-6HKIX Tier III certified |
|---|---|
| Displacement | 475 in³ |
| Power Measured @ | 2,000 rpm |
| Net Power | 248.0 hp |
| Aspiration | turbocharged |
| Torque Measured @ | 1,500 rpm |
| Max Torque | 796 lb-ft |
Dimensions
| Ground Clearance | 228 in |
|---|---|
| Height - Top of Cab | 121 in |
| Length of Track on Ground | 159 in |
| Tail Swing Radius | 137 in |
| Width to Outside of Tracks | 134 in |
| Removal Counterweight Clearance | 576 in |
| Digging Depth | 312 in |
| Digging Reach | 312 in |
Undercarriage
| Ground Pressure | 7 psi |
|---|---|
| Track Gauge | 102 in |
| Number of Track Rollers per Side | 8 |
| Max Travel Speed | 3.4 mph |
| Shoe Size | 32 in |
| Number of Shoes per Side | 48 |
| Number of Carrier Rollers per Side | 2 |
| Drawbar Pull | 60,923 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 320 in |
|---|---|
| Max Reach Along Ground | 462 in |
| Max Loading Height | 298 in |
| Max Vertical Wall Digging Depth | 282 in |
| Max Cutting Height | 420 in |
| Shipping Length of Unit | 438 in |
| Shipping Height of Unit | 139 in |
Bucket
| Reference Bucket Capacity | 2.11 yd³ |
|---|---|
| Maximum Bucket Capacity | 3.00 yd³ |
| Minimum Bucket Capacity | 1.29 yd³ |
Swing Mechanism
| Swing Speed | 10 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 289 in |
|---|---|
| Max Vertical Wall Digging Depth | 251 in |
| Max Cutting Height | 408 in |
| Max Loading Height | 28,500 in |
| Max Reach Along Ground | 432 in |
| Shipping Length of Unit | 435 in |
| Shipping Height of Unit | 130 in |
Boom/Stick Excavator Option 3
| Max Digging Depth | 265 in |
|---|---|
| Max Cutting Height | 407 in |
| Max Loading Height | 282 in |
| Max Vertical Wall Digging Depth | 235 in |
| Max Reach Along Ground | 413 in |
| Shipping Length of Unit | 438 in |
| Shipping Height of Unit | 139 in |
