Case
Kobelco
SK350LC-10 H&W
Excavator
35 specifications
1 / 5
Image 1 of 5
Specifications
52 data points
Operating Specifications
| Operating Weight | 79,146 lb |
|---|---|
| Fuel Capacity | 153.3 gal |
| Hydraulic Pump Flow Capacity | 150.1 gal/min |
| Hydraulic System Fluid Capacity | 92.5 gal |
| Hydraulic System Relief Valve Pressure | 4,975 psi |
| Engine Oil Capacity | 8.8 gal |
| Cooling System Fluid Capacity | 11.1 gal |
| Operating Voltage | 24 V |
| Swing Drive Fluid Capacity | 1.6 gal |
| Alternator Supplied Amperage | 50 A |
Engine
| Engine Model | AA-6HK1XQB |
|---|---|
| Displacement | 475 in³ |
| Power Measured @ | 2,000 rpm |
| Net Power | 248.0 hp |
| Aspiration | Turbocharged |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Height - Top of Cab | 124 in |
| Length of Track on Ground | 159 in |
| Tail Swing Radius | 137 in |
| Width to Outside of Tracks | 126 in |
| Removal Counterweight Clearance | 48 in |
Undercarriage
| Ground Pressure | 10 psi |
|---|---|
| Track Gauge | 103 in |
| Number of Track Rollers per Side | 8 |
| Max Travel Speed | 3.5 mph |
| Shoe Size | 24 in |
| Number of Shoes per Side | 48 |
| Number of Carrier Rollers per Side | 2 |
Boom/Stick Excavator Option 1
| Max Digging Depth | 248 in |
|---|---|
| Max Reach Along Ground | 394 in |
| Max Loading Height | 268 in |
| Max Cutting Height | 389 in |
| Shipping Length of Unit | 444 in |
| Shipping Height of Unit | 142 in |
Bucket
| Reference Bucket Capacity | 1.80 yd³ |
|---|---|
| Maximum Bucket Capacity | 2.69 yd³ |
| Minimum Bucket Capacity | 0.99 yd³ |
Swing Mechanism
| Swing Speed | 10 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 265 in |
|---|---|
| Max Vertical Wall Digging Depth | 235 in |
| Max Cutting Height | 407 in |
| Max Loading Height | 282 in |
| Max Reach Along Ground | 413 in |
| Shipping Length of Unit | 439 in |
| Shipping Height of Unit | 139 in |
Boom/Stick Excavator Option 3
| Max Digging Depth | 289 in |
|---|---|
| Max Cutting Height | 409 in |
| Max Loading Height | 285 in |
| Max Vertical Wall Digging Depth | 251 in |
| Max Reach Along Ground | 433 in |
| Shipping Length of Unit | 435 in |
| Shipping Height of Unit | 130 in |
