Case
Kobelco
SK350LC-10 H&W
Excavator
35 specifications
1 / 5
Image 1 of 5
Specifications
50 data points
Operating Specifications
| Operating Weight | 76,500 lb |
|---|---|
| Fuel Capacity | 153.3 gal |
| Hydraulic Pump Flow Capacity | 150.6 gal/min |
| Hydraulic System Fluid Capacity | 92.5 gal |
| Cooling System Fluid Capacity | 9.4 gal |
Engine
| Engine Model | AL-6HK1X |
|---|---|
| Displacement | 475 in³ |
| Power Measured @ | 1,900 rpm |
| Net Power | 265.6 hp |
| Torque Measured @ | 1,500 rpm |
| Max Torque | 769 lb-ft |
| Engine Make | Isuzu |
| Stroke | 5 in |
| Bore | 5 in |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Height - Top of Cab | 128 in |
| Wheelbase | 159 in |
| Length of Track on Ground | 197 in |
| Tail Swing Radius | 141 in |
| Width to Outside of Tracks | 126 in |
Undercarriage
| Ground Pressure | 8 psi |
|---|---|
| Number of Track Rollers per Side | 8 |
| Max Travel Speed | 3.4 mph |
| Number of Shoes per Side | 48 |
| Number of Carrier Rollers per Side | 2 |
| Drawbar Pull | 59,350 lb |
Boom/Stick Excavator Option 1
| Max Digging Depth | 289 in |
|---|---|
| Max Reach Along Ground | 433 in |
| Max Loading Height | 285 in |
| Max Cutting Height | 409 in |
| Shipping Length of Unit | 439 in |
| Shipping Height of Unit | 135 in |
Swing Mechanism
| Swing Speed | 10 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Digging Depth | 248 in |
|---|---|
| Max Cutting Height | 389 in |
| Max Loading Height | 268 in |
| Max Reach Along Ground | 394 in |
| Shipping Length of Unit | 448 in |
| Shipping Height of Unit | 144 in |
Boom/Stick Excavator Option 3
| Max Digging Depth | 265 in |
|---|---|
| Max Cutting Height | 407 in |
| Max Loading Height | 282 in |
| Max Reach Along Ground | 413 in |
| Shipping Length of Unit | 443 in |
| Shipping Height of Unit | 144 in |
Boom/Stick Excavator Option 4
| Max Digging Depth | 322 in |
|---|---|
| Max Cutting Height | 421 in |
| Max Reach Along Ground | 462 in |
| Max Loading Height | 298 in |
| Shipping Length of Unit | 442 in |
