Case
Kobelco
SK350LC-10 H&W
Excavator
35 specifications
1 / 5
Image 1 of 5
Specifications
71 data points
Operating Specifications
| Operating Weight | 82,484 lb |
|---|---|
| Arm Breakout Force | 40,241 lb |
| Arm size | 127,954 in |
Engine
| Engine Model | Isuzu 6 HK1X |
|---|---|
| Displacement | 476 in³ |
| Power Measured @ | 1,900 rpm |
| Net Power | 268.0 hp |
| Max Torque | 4 lb-ft |
| Engine Make | Isuzu |
| Bore | 5 in |
| Stroke | 5 in |
| Fuel Type | Requires ultra-low sulfur fuel B5 biodiesel tolerant |
| Emission Tier Level | Tier 4 |
| Fuel injection | Direct injection - electronic |
| Air filter type | Dry type element with warning restriction indicator |
| Fuel Filter | Replaceable full flow spin-on cartridge |
| Oil Filter | Replaceable full flow spin-on cartridge |
Weights
| Counterweight | 16,314 lb |
|---|
Hydraulic System
| Main pump - Maximum flow | 128.4 gal |
|---|---|
| System relief pressure | 50 psi |
Dimensions
| Ground Clearance | 19 in |
|---|---|
| Tail Swing Radius | 141 in |
| Overall Height | 137 in |
| Track Shoe Width | 32 in |
| Cab height | 125 in |
| Center to center - idler to sprocket | 159 in |
| Ground pressure | 8 psi |
| Boom length | 1 in |
| Minimum ground clearance | 19 in |
Transmission
| Max Speed | 3.5 mph |
|---|
Undercarriage
| Track Shoe Width | 32 in |
|---|
Brakes & Steering
| Service brake | SAHR disc - each motor |
|---|---|
| Brakes Type | Mechanical disc |
| Travel control | Dual stage relief or counter balance design |
Fluid Capacities
| Hydraulic system | 92.5 gal |
|---|---|
| Hydraulic Tank | 46.3 gal |
| Cooling system | 10.1 gal |
| Engine oil w/ filter change | 12.7 gal |
| Swing drive | 1.4 gal |
| Final Drive | 2.6 gal |
| DEF Tank | 40.2 gal |
Boom/Stick Excavator Option 1
| Max Digging Depth | 289 in |
|---|---|
| Max Reach Along Ground | 432 in |
| Max Vertical Wall Digging Depth | 251 in |
| Minimum swing radius | 178 in |
| Bucket rotation | 173 ° |
| Mximum dig radius | 440 in |
| Dig radius at ground line | 4,323 in |
| Dump height | 285 in |
General Specifications
| Operating Weight lbs (kg) | 82,483 (37,414) Starting 2025 Model Year |
|---|---|
| Digging Depth ft (m) | 26.7 (8.1) Starting 2025 Model Year |
| Digging Reach ft. (m) | 38.4 (11.7) Starting 2025 Model Year |
| Engine hp (kW) | 268 (200) Starting 2025 Model Year |
Swing Mechanism
| Swing Speed | 10 rpm |
|---|
Boom/Stick Excavator Option 2
| Minimum swing radius | 178 in |
|---|---|
| Bucket rotation | 173 ° |
| Dig radius at ground line | 412 in |
| Dump height | 280 in |
| Maximum dig radius | 419 in |
| Maximum reach height | 409 in |
Boom/Stick Excavator Option 3
| Minimum swing radius | 178 in |
|---|---|
| Overall height | 137 in |
| Bucket rotation | 173 ° |
| Maximum dig radius | 469 in |
| Dig radius at ground line | 461 in |
| Dump height | 297 in |
| Maximum reach height | 419 in |
Performance
| Lift over end Max. reach | 9,833 lb |
|---|---|
| Lift over side Max. reach | 8,488 lb |
| Lift over end 10' radius | 22,840 lb |
| Lift over side 10' radius | 22,840 lb |
