Case
Kobelco
SK350LC-10 H&W
Excavator
35 specifications
1 / 5
Image 1 of 5
Specifications
81 data points
Operating Specifications
| Operating Weight | 109,349 lb |
|---|---|
| Arm Breakout Force | 49,458 lb |
| Arm size | 133,072 in |
Engine
| Engine Model | Isuzu 6 UZ1X |
|---|---|
| Displacement | 598 in³ |
| Power Measured @ | 2,000 rpm |
| Net Power | 362.0 hp |
| Max Torque | 1,005 lb-ft |
| Engine Make | Isuzu |
| Bore | 5 in |
| Stroke | 6 in |
| Fuel Type | Requires ultra-low sulfur fuel B5 biodiesel tolerant |
| Emission Tier Level | Tier 4 |
| Fuel injection | Direct injection - electronic |
| Air filter type | Dry type element with warning restriction indicator |
| Fuel Filter | Replaceable full flow spin-on cartridge |
| Oil Filter | Replaceable full flow spin-on cartridge |
Weights
| Counterweight | 22,928 lb |
|---|
Hydraulic System
| Main pump - Maximum flow | 192.4 gal |
|---|---|
| System relief pressure | 4,550 psi |
Dimensions
| Ground Clearance | 22 in |
|---|---|
| Tail Swing Radius | 148 in |
| Overall Height | 170 in |
| Track Shoe Width | 36 in |
| Cab height | 138 in |
| Center to center - idler to sprocket | 186 in |
| Ground pressure | 8 psi |
| Boom length | 305 in |
| Minimum ground clearance | 33 in |
Transmission
| Max Speed | 2.7 mph |
|---|
Undercarriage
| Track Shoe Width | 36 in |
|---|
Brakes & Steering
| Service brake | SAHR disc - each motor |
|---|---|
| Brakes Type | Mechanical disc |
| Travel control | Dual stage relief or counter balance design |
Fluid Capacities
| Fuel Tank | 171.8 gal |
|---|---|
| Hydraulic system | 121.6 gal |
| Cooling system | 12.5 gal |
| Hydraulic Tank | 60.8 gal |
| Engine oil w/ filter change | 9.6 gal |
| Swing drive | 2.8 gal |
| Final Drive | 4.0 gal |
| DEF Tank | 40.2 gal |
Boom/Stick Excavator Option 1
| Max Digging Depth | 305 in |
|---|---|
| Max Reach Along Ground | 471 in |
| Max Vertical Wall Digging Depth | 261 in |
| Minimum swing radius | 196 in |
| Bucket rotation | 176 ° |
| Mximum dig radius | 471 in |
| Dig radius at ground line | 463 in |
| Dump height | 303 in |
General Specifications
| Operating Weight lbs (kg) | 109,300 (49,600) Starting 2025 Model Year |
|---|---|
| Digging Depth ft (m) | 30.2 (9.2) Starting 2025 Model Year |
| Digging Reach ft. (m) | 42.8 (13.1) Starting 2025 Model Year |
| Engine hp (kW) | 362 (270) Starting 2025 Model Year |
Swing Mechanism
| Swing Speed | 9 rpm |
|---|
Boom/Stick Excavator Option 2
| Max Vertical Wall Digging Depth | 236 in |
|---|---|
| Minimum swing radius | 194 in |
| Bucket rotation | 176 ° |
| Dig radius at ground line | 432 in |
| Dump height | 292 in |
| Maximum dig radius | 442 in |
| Maximum reach height | 427 in |
Boom/Stick Excavator Option 3
| Max Digging Depth | 329 in |
|---|---|
| Minimum swing radius | 193 in |
| Overall height | 170 in |
| Bucket rotation | 176 ° |
| Maximum dig radius | 493 in |
| Dig radius at ground line | 484 in |
| Dump height | 328 in |
| Maximum reach height | 443 in |
Boom/Stick Excavator Option 4
| Max Digging Depth | 362 in |
|---|---|
| Minimum swing radius | 199 in |
| Bucket rotation | 176 |
| Dig radius at ground line | 514 in |
| Dump height | 318 in |
| Maximum dig radius | 522,442 in |
| Maximum reach height | 451 in |
Performance
| Lift over end Max. reach | 20,040 lb |
|---|---|
| Lift over side Max. reach | 11,707 lb |
| Lift over end 10' radius | 20,327 lb |
| Lift over side 10' radius | 20,327 lb |
